NOVA POS

15" POS System

Innovative Slim Design

A trend-setting POS system with a sleek and slim modern design

A design that makes your store space more stylish and distinctive.

Ultra-slim bezel

The slim bezel design reduces overall bulk while
maximizing screen space, allowing users to stay
focused on the POS monitor.

Sleek and durability aluminum diecasting body

Aluminum Diecasting Body

A clear and comfortable display

With optical bonding technology, the monitor reduces glare even under
intense lighting conditions in-store, helping to minimize eye strain during
prolonged use.

Reduce light
refraction

Provides a clear
display

Excellent heat dissipation

Featuring IMU’s exclusive cooling technology, this product is engineered to optimize
heat management. Key components are designed with aluminum to effectively reduce
heat in POS systems during prolonged use,ensuring optimal performance and durability for extended
product lifespan.

Equipped with a powerful high performance processor

Equipped with an Intel® high-performance processor, offering improved speed and consistent, powerful performance.

4GB up to 16GB

Optional

128GB up to 512GB

Optional

Windows10
Windows11

Various display types Option

Display size can be selected based on the user environment.

15" (1024 x 768) l 4:3

15.6" (1920 x 1080) l 16 :9

Accessories Option

Customer display Option

The 15” and 15.6” customer monitors
can be separated and used independently with an extension cable,
allowing a distance of up to 3 meters.

Display Options

YOU CAN SELECT AND USE VARIOUS COMBINATIONS

OPTION 01

Main Display + Secondary Display

15” + 9.7”
15” + 15”
15” + 15.6
15” + CDP”

I/O ports

Ultra-slim POS that fits perfectly in any store!

From cafes and specialty shops to premium lifestyle

Multiplex

Hotel / Lounge

Hair Salon

Retail Store

Different UP solutions for your store

The program can be configured according to the store’s concept and the user friendly UI provides a quick operation
from an order being placed to payment. Multiple languages are supported and local businesses can also be linked.

UP SOLUTIONS

Specifications

N9

Peripheral Options
System
System	Processor Intel® Processor N97, up to 3.60 GHz(Fanless)
	Chipset / BIOS Intel® Alder Lake-N SoC / AMI UEFI
	Storage NVMe M.2 2280 128GB (SSD 256/512GB, optional)
	Memory 4GB SO-DIMM DDR4 3200MHz x 1 (Max 16GB, optional)
	Graphics Intel® UHD Graphics
	OS Windows 10 IoT Enterprise(64bit), Windows 11 IoT Enterprise(64bit)
Display
Display	Primary Display Type 15" LED Backlight (1024 x 768 Resolution, 4:3) 15.6" LED Backlight (1920 x 1080 Resolution, 16:9)
Display	Touch PCAP 10 Point Multi-touch
I/O Interfaces
I/O Interfaces	Rear Top & Bottom Ports
	USB Rear : 3 x USB 2.0, 1 x USB 2.0(RJ11) / Side : 2 x USB 3.0 , 1 x USB Type-C(DP alt mode support)
	Serial 4 (3 x RJ50, 1 x RJ11)
	Audio 1 x Audio-out / 3.5mm
	Extend Displays 2 x MiniDP output(1st Display, 2nd Display)
	LAN 1 x RJ45 (Base-T 10,100,1000m/bps Ethernet)
	Speaker 1 x 3W
Peripheral Options
	Secondary Display • LCD Type: 9.7" or 15" or 15.6" - by single cable(Power & Data)
	Customer Display (CDP) FSTN LCD Type(20 columns x 2 lines)
	Card Reader (MSR / SCR) Smart Card Reader: ISO/IEC7816 EMV Level 1 / Magnetic Stripe Reader: ISO 7811 ID-1 All tracks
	Dallas Reader Dallas Reader(i-button): 6 characters / prefix and suffix
	Wireless 802.11 b/g/n/ac, Bluetooth 5.1
Physical Dimension
Physical Dimension
	Dimension (W x D x H) 15" : 328 x 215 x 338 (mm)
	Weight 15" : 4.2 kg
	Box Dimension
Box Dimension
	Dimension (W x D x H) 15" : 390 x 270 x 390 (mm)
	Weight 15" : 6.5 kg
	Environment
Environment
	Power Supply DC 12V/5A (AC 100V~240V, 60W)
	Temperature Operating Temp : 0~40℃ / Storage Temp : -20~60℃ / Humidity : 20% to 90%
	Certifications CE, FCC, KC

* Specifications are subject to change without prior notice. * The weight of the box varies depending on the components and the main board. (includes box weight)
